SGM2033.pdf? Operating Input Voltage Range: 1.8V to 5.5V
? Fixed Output Voltage Range: 1.2V to 5.0V
? Adjustable Output Voltage Range: 1.2V to 5.0V
? Output Short to GND Protection
? Output Current Limit: 500mA (TYP)
? Over-Temperature Protection: +165℃
? Fast Load Transient Response
Ultra-Low Quiescent Current: 13.5μA (TYP)
? Shutdown Current: 0.1μA (TYP)
? Stable with 1μF Small Case Size Ceramic Capacitors
? -40℃ to +125℃ Operating Temperature Range
? Available in Green SOT-23-5 and UTDFN-1×1-4AL Packages
? Input Voltage Range : 2.2V to 5.5V
? Adjustable Output Voltage : 1.2V to 4.5V
? PSRR85dB @ 1kHz (20mA)
? 80dB @ 10kHz (20mA)
? Output Current : 250mA
? Very Low Dropout : 120mV
? Very Low IQ (Enabled) : 16?A
? Virtually Zero IQ (Disable) : < 1?A
? Very Low IG (Enabled) : 16?A
? Start-up Time : 80?s
? ?40°C to 125°C Operating Junction Temperature Range
? Excellent Noise Immunity
Fast Response Overload and Line Transient
? Stable with a 1?F Input and Output Ceramic Capacitors
? Accurate Output Voltage 2% Overload,
Line, Process, and Temperature Variations
? Over-Current Protection
? Over-Temperature Protection
